YOUNGJIN ROTARY

PRODUCT

First in Korea!
Best in Korea! Youngjin Machinery Co., Ltd.

Feature of product
  • High strength and longer lasting durability by specially designed side gear drive
  • Light weight more than the same description
  • Field selectable Cat. 1 type lower hitch
  • Standard Slip-Clutch shaft to protect tractor
Specification
Units : Inch, Lbs, Ea
ER MODEL SPECIFICATIONS
Model ER 048 ER 062 ER 074 ER 084
Recommended Tractor HP 18-35 26-45 40-55 50-65
Tiller Size Length 26.9 27.6 27.6 31.4
Width 52.2 67.1 79.3 89.6
height 32.3 33.1 33.1 36.5
Weight 356 516 654 896
Tilling Width 48 62 74 84
Tilling Depth(max) 6.5 7.5 7.5 8
No. of Franges 5 7 9 9
No. of Blades 20 42 54 48
Hitch Cat. 0 & Ⅰ Cat. 0 & Ⅰ Cat. 0 & Ⅰ Cat. 0 & Ⅱ
Rotot Swing Diameter 15.8 18.3 18.3 18.9

※ Specifications, designs and dimensions are subject to change without prior notice
