YOUNGJIN ROTARY

PRODUCT

First in Korea!
Best in Korea! Youngjin Machinery Co., Ltd.

Feature of product
  • Special Group Seal System to protect drive shaft leakage
  • Minimized Tillage-resistance by blades arrangement
  • Effective tillage-work by side gear driving system
  • Specially designed side gear pin to allow maximum power efficiency
Specification
Units : Inch, Lbs, Ea
YJR MODEL SPECIFICATIONS
Model YJR 062 YJR 074 YJR 080 YJR 084 YJR 090
Recommended Tractor HP 26-45 40-65 55-85 55-85 65-100
Tiller Size Length 27.6 38.2 41.3 41.3 41.3
Width 68.9 80.1 87.4 92.2 99.2
height 33.5 44.5 48.2 48.2 48.2
Weight 651 946 442 1176 1208
Tilling Width 62 74 80 84 90
Tilling Depth(max) 7 8 8 8 8
No. of Franges 8 7 8 8 9
No. of Blades 48 42 48 48 54
Hitch Cat. Ⅰ& Ⅱ Cat. Ⅰ& Ⅱ Cat. Ⅱ Cat. Ⅱ Cat. Ⅱ
Rotot Swing Diameter 17.3 20.4 20.4 20.4 20.4

※ Specifications, designs and dimensions are subject to change without prior notice
