YOUNGJIN ROTARY

PRODUCT

First in Korea!
Best in Korea! Youngjin Machinery Co., Ltd.

Feature of product
  • Low noise, high strength spiral bevel with 4 speed gear box
  • High durable spline design
  • Special triple group seal system to protect bearing case from strange-material in-out
Specification
Units : Inch, Lbs, Ea
GM MODEL SPECIFICATIONS
Model GM 080 GM 090 GM 102
Recommended Tractor HP 55-85 65-100 70-125
Tiller Size Length 41.3 41.3 41.3
Width 87.6 94.9 106.7
height 48.2 48.2 48.2
Weight 1171 1279 1737
Tilling Width 80 90 102
Tilling Depth(max) 8 8 9.5
No. of Franges 8 9 10
No. of Blades 48 54 60
Hitch Cat. Ⅱ Cat. Ⅱ Cat. Ⅱ
Rotot Swing Diameter 20.4 20.4 23

※ Specifications, designs and dimensions are subject to change without prior notice
