• Greater depth penetration resulting in moving and pulverizing more soil
• More of the residue in the soil
• Reverse action ‘sucks’tiller into ground does not work on top of hard ground like forward tiller can
• Variable application in landscaping, nurseries, gardens and light commercial use

SR MODEL SPECIFICATIONS

Model		SR 052	SR 060	SR 072
Recommended Tractor HP		15-35	26-35	35-50
Tiller Size	Length	28.4	28.4	28.6
	Width	58.8	66.5	77.4
	height	36.6	36.6	38.8
Weight		520	540	660
Tilling Width		52	60	72
Tilling Depth(max)		7.5	7.5	8
No. of Franges		5	6	7
No. of Blades		30	36	42
Hitch		Cat. Ⅰ	Cat. Ⅰ	Cat. Ⅰ
Rotot Swing Diameter		18.1	18.1	19.2

※ Specifications, designs and dimensions are subject to change without prior notice
